Hydraulic Hose HYDRAULIC HOSE
.com ®

R2 | High Pressure, 2-Wire

Meets all requirements of SAE 100R2 AT
Recommended for hydraulic service with petroleum and water-base fl uids. No skiving
Tube: oil-resistant synthetic rubber required. Long-lasting cover is well suited for mobile hydraulics.
Reinforcement: two braids of high-tensile
steel wire Maximum Minimum
Inside Outside Operating Minimum Bend Reel Reel Price Cut Price
Cover: oil and abrasion-resistant Item # Diameter Diameter (PSI) Burst (PSI) Radius Length* (per foot) (per foot)
synthetic rubber R2-04 1/4" 0.59" 5,800 23,200 4" 500'
Temperature range: -40° to +212° F
R2-06 3/8" 0.75" 4,785 19,140 5" 450'
Recommended hose fi ttings: R2-08 1/2" 0.88" 4,000 16,000 7" 320'

R2-10 5/8" 0.98" 3,625 14,500 8" 520'
R2-12 3/4" 1.16" 3,120 12,480 9½" 400'
Braided Hose Fittings: page 14 R2-16 1" 1.50" 2,395 9,580 12" 200'
R2-20 1¼" 1.87" 1,815 7,260 16½" 131'
R2-24 1½" 2.17" 1,305 5,220 20" 131'
R2-32 2" 2.66" 1,160 4,640 25" 131'
SAE 100R2 AT Field-Attachable
Hose Fittings: page 39 * Reel may not contain one continuous length of hose.

HT | Hydraulax Tough™ 2-Wire

MSHA approved
Hydraulax Tough™ is the ideal hose for high abrasion environments. In addition to its
Tube: oil-resistant synthetic rubber recognised benefi ts of excellent resistance to ozone, UV radiation, high temperatures
Reinforcement: two braids of high-tensile and salt water, it meets the special requirements of the underground coal mining
steel wire industry.
Cover: synthetic rubber with the following
Recommended for hydraulic service with petroleum and water-base fl uids. No skiving
key characteristics:
required. Long-lasting tough cover is ideal for mobile hydraulics in harsh environments.
• superior abrasion resistance
• excellent ozone and UV resistance
Maximum Minimum
• weather and salt water resistance Inside Outside Operating Minimum Bend Reel Reel Price Cut Price
Item # Diameter Diameter (PSI) Burst (PSI) Radius Length* (per foot) (per foot)
• fl ame resistance according to MSHA
HT-04 1/4" 0.53" 6,525 26,100 1.8" 400'
and DSK (LOBA) specs.
• antistatic HT-06 3/8" 0.68" 5,585 22,340 2.8" 525'
Temperature range: -40° to +212° F HT-08 1/2" 0.81" 5,000 20,000 3.5" 360'
Recommended hose fi ttings: HT-10 5/8" 0.93" 4,205 16,820 5.1" n/a n/a
HT-12 3/4" 1.09" 4,060 16,240 6.3" 426'
HT-16 1" 1.40" 2,900 11,600 8.27" n/a n/a
Braided Hose Fittings: page 14
(up to size -12 only)

W Series Hose Fittings: page 21
